A705-40-880 Issue B
Page 12 © Edwards Limited 2011. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.8 Coolant type
The pump is supplied filled with Edwards coolant which is monopropylene based, and is both an antifreeze and a
corrosion inhibitor. Spare Edwards coolant is available: refer to Section 7.3. If you will use another coolant type to
replenish lost coolant:
It must prevent the formation of visible oxide sludge and scale deposits.
It must provide frost protection down to a temperature of -14 °C, when mixed in accordance with the
manufacturer’s recommendations.
It must be compatible with the materials of construction of the cooling-jacket; that is: SG iron, copper, brass
and fluoroelastomer (Viton) seals.
It must comply with the requirements of BS 6580-1992 and BS 5117.
It must be based on monopropylene glycol or ethylene glycol fluid.
It must not contain amines.
The coolants shown in Table 8 may be suitable for use in the EDP pumps. All of these coolants are amine free,
automotive grade, ethylene glycol antifreezes and must be diluted to between 35% to 50% by volume with water to
provide the required cooling protection. However, we recommend that you use Edwards coolant; Edwards cannot
guarantee that other types of coolant will provide the best corrosion protection for the pump.
2.9 Lubrication data
Note: Edwards Material Safety Data Sheets for some of the oils and greases specified below are available on
request.
2.10 Noise data
Table 8 - Possible alternative coolants
Manufacturer Product
BP (Chemicals) NAPGEL C2230 (Universal)
Texaco Lubricants Texaco Engine Coolant ETX 6024
Castrol Castrol Antifreeze
Table 9 - Lubrication data
Gearbox
Oil capacity: minimum 3.35 l / 0.89 US gal
Oil capacity: maximum 3.85 l / 1.02 US gal
Recommended oil (supplied) Mobil SHC 629
High vacuum bearings
Grease type Perfluoropolyether
Recommended grease Fomblin CR861
Table 10 - Noise data
EDP80 EDP160 EDP250 EDP400
50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz
Typical continuous A-weighted
sound pressure level
73 dB(A) 73 dB(A) 78 dB(A) 78 dB(A) 79 dB(A) 79 dB(A) 82 dB(A) 82 dB(A)
