Technical Data
A546–00–880 Issue C
2.4 Connections
Table 5 - iGX connector types
Description
Mating connector description/
external supply rating
Internal supply rating
PDT1 XLR type 5-way plug 24 V d.c. 0.75 A
Mains connection Weidmuller HDC 16D free socket, PG21, 6
mm
2
stranded wire, 13-18 mm cable OD
Ethernet connection Standard RJ45 type or Neutrik Ethercon
RJ45
IEE802.3 10BaseT Ethernet
LON module connection XLR type 4-way plug 24 V d.c. 0.75 A
PDT2 XLR type 5-way plug 24 V d.c. 0.75 A
Gate valve interface* CPC 9-way plug, standard gender, socket
contacts
24 V d.c. (48 V peak), 100 mA
EMO (on T variant only)
6 - common and 7 - normally closed
CPC 7-way plug, standard gender, socket
contacts 30 V d.c. 0.5 A
EMS* XLR type 6-way plug
External emergency stop switch
1 - supply, 2 - return
24 V d.c. 100 mA
Internal emergency stop switch
3 - common, 4 - normally open
30 V a.c. 1 A
60 V d.c. 0.55 A
Comms supply
5 - supply, 6 - return
24 V d.c. 0.5 A
Accessory module interface* Preh locking DIN 8-way plug 24 V d.c. 1.3 A
GRC interface* DIN type 6-way plug
1 - Normally open and 3 - common 30 V a.c. 1 A
2 - Normally open and 4 - normally
closed
30 V d.c. 1 A
5 - Normally open and 6 - common 60 V d.c. 0.5 A
