A546–00–880 Issue C
Page 24 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trade marks of Edwards Limited.
OPERATION
MicroTIM operation:
5. Use your control equipment to set the pump start/stop signal to the interface connector and check that the
Running LED is illuminated.
z Control must be taken with the MicroTIM. The message 'MicroTIM IN CONTROL' will be displayed on the PDT if
connected.
PDT operation:
6. If the system is to be operated using the PDT;
z Connect the PDT to the required PDT connection, front (Figure 4, item 10) rear (Figure 2, item 9)
z Control must be taken with the PDT - press 'Control' button. The message 'PDT1 IN CONTROL' will be
displayed if the front connection is used and the message 'PDT2 IN CONTROL' will be displayed if the rear
connection is used.
z Press Start button.
z Press ENTER.
z The system will start and the Running LEDs will be illuminated.
4.2 Status indicators
Refer to Figure 3 and 4.
4.3 Manual shut-down
The pump can be shutdown using either the MicroTIM, the PDT or the front panel local control membrane. Note that
only the item in control can stop the pump (refer to Section 1.4).
Front panel local control membrane operation:
Press and hold the stop button (Figure 4, item 3) until the running LED (Figure 4, item 8) flashes. The running LED
will then turn off when the pump has shutdown.
MicroTIM operation:
Use your control equipment to reset the pump start/stop signal to the interface connector. The Running LED
(Figure 4, item 8) will then go off, and the pump running status output signal will open.
PDT operation:
Selecting either ’normal’ or ’fast’ shutdown will shut the pump down immediately.
If the pump is not going to be required for some time, switch off the electrical supply and the cooling-water supply.
If you shut the system down and don’t isolate it from the electrical supply, do not disconnect the
Pump Display Terminal or release control from the Pump Display Terminal or front panel. If you do
the system could be started by another Module.
