A540-55-880 Issue D
Page 8 © Edwards Limited 2015. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.2 Performance data
Figure 5 - Continuous operating zones
Table 3 - Performance data
Pump
Characteristics
Average values
*
*
Average values are the mean value taken from a sample of typical production units.
Factory test limits
Typical peak
pumping speed
Ultimate Ultimate
Maximum continuous
inlet pressure
†
†
The maximum pressure at which the pump will operate without generating warnings or alarms.
Units m
3
/h mbar mbar mbar
iXL600 600 0.001 0.005 1000
iXL600N
‡
(10 slm purge)
‡
For iXL600N and iXL1000N with no purge use values for iXL600 and iXL1000.
600 0.002 0.008 1000
iXL1000 930 0.001 0.005 1000
iXL1000N
‡
(10 slm purge)
930 0.002 0.008 1000
Item Description
1 Continuous operation - no warnings or alarms
2 Discontinuous operation - time to alarm indicated
