Technical data
D397-50-880 Issue C
Table 10 - Pin connections for 15-way sub-miniature ‘D’ type socket
Pin Allocation
1+24 V d.c. power output (Connect all three 24 V pins)
2 Not connected
3 Not connected
4RS232 Transmit
5 Serial enable link (Resistor to 0 V)
6+24 V d.c. power output
7RS232 Receive
80 V power (Connect all three 0 V pins)
9+24 V d.c. power output (Connect all three 24 V pins)
10 Chassis (box)
11 +24 V d.c. power output (Connect all three 24 V pins)
12 Not connected
13 0 V power (Connect all three 0 V pins)
14 0 V power (Connect all three 0 V pins)
15 Not connected
Shell Chassis (box)
