Edwards TIC User Manual

© Edwards Limited 2010. All rights reserved. Page 25
Edwards and the Edwards logo are trademarks of Edwards Limited.
Operation
D397-50-880 Issue C
4.8.1 Front panel lock
A "Common" parameter. The options are either locked or unlocked. This parameter is always sent. The panel lock
allows monitoring only and scrolling through screens.
Note:
It is advised that the locked option is selected. Front panel control may be overridden by the Profibus command
leading to unexpected pump or gauge behaviour.
Module No. Module description Compatibility
No of output
bytes
No of input
bytes
No of
Parameter
bytes
907 Turbo normal Any TIC controller with
turbo control
None 3 None
908 Turbo standby Any TIC controller with
turbo control
13None
909 Turbo cycle time Any TIC controller with
turbo control
None 5 None
910 Backing pump control Any TIC controller with
backing control
13None
911 Backing pump speed
(Reserved)
Any TIC controller with
backing control
04None
912 Backing pump power Any TIC controller with
backing control
None 4 None
913 Gauge1 Any TIC controller with
gauge control
1817
914 Gauge2 Any TIC controller with
gauge control
1817
914 Gauge3 Any TIC controller with
gauge control
1817
916 Relay 1 Any TIC controller None 3 14
917 Relay 2 Any TIC controller None 3 14
918 Relay 3 Any TIC controller None 3 14
919 TIC power supply temp Any TIC controller with
turbo control
None 4 None
920 TIC internal temp Any TIC controller None 4 None
921 Analogue output Any TIC controller None 3 4
922 TIC vent valve Any TIC controller with
turbo control
None 3 3
923 Heater band Any TIC controller with
turbo control
153
924 Air cooler (Fan) Any TIC controller with
turbo control
None 3 3
Bytes Parameter Option Description of Parameter
1st Module number Cannot be changed.
2nd
3rd State 0 = unlocked, 1 = control locked.
