Edwards TIC User Manual

D397-50-880 Issue C
Page 54 © Edwards Limited 2010. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Appendix A2
Appendix A2 Alert ID
No Alert = 0
ADC Fault = 1
ADC Not Ready = 2
Over Range = 3
Under Range = 4
ADC Invalid = 5
No Gauge = 6
Unknown = 7
Not supported = 8
New ID = 9
Over Range = 10
Under Range = 11
Over Range = 12
Ion EM Timeout = 13
Not Struck = 14
Filament Fail = 15
Mag Fail = 16
Striker Fail = 17
Not Struck = 18
Filament Fail = 19
Cal Error = 20
Initialising = 21
Emission Error = 22
Over Pressure = 23
ASG Cant Zero = 24
RampUp Timeout = 25
Droop Timeout = 26
Run Hours High = 27
SC Interlock = 28
ID Volts Error = 29
Serial ID Fail = 30
Upload Active = 31
DX Fault = 32
Temp Alert = 33
Sys Inhibit = 34
Ext Inhibit = 35
Temp Inhibit = 36
No Reading = 37
No Message = 38
NOV Failure = 39
No Tube = 42
