Edwards TIC User Manual

© Edwards Limited 2010. All rights reserved. Page 43
Edwards and the Edwards logo are trademarks of Edwards Limited.
Maintenance
D397-50-880 Issue C
Software
Module
No.
Parameter Units Default value
904 Master gauge Numbered
options
0 ( = None)
904 Master gauge units Numbered
options
59 ( = Pascals)
904 ON Setpoint IEEE-754 format 0x40200000 ( = 2.5E-4 pascals)
904 OFF setpoint IEEE-754 format 0x41200000 ( = 1.0E-3 pascals)
904 Control from gauge
selected.
Numbered
options
0 ( = disabled)
904 Start delay Minutes 0
905 Max ramp time to 50%
speed.
Minutes 8
905 Max droop time below 50%
speed
Minutes 8
913 Master object Numbered
options
0 ( = None)
913 Master object units Numbered
options
59 ( = Pascals)
913 ON Setpoint IEEE-754 format 0x40200000 ( = 2.5E-4 pascals)
913 OFF setpoint IEEE-754 format 0x41200000 ( = 1.0E-3 pascals)
913 Control from object
selected.
Numbered
options
0 ( = disabled)
913 Gas type Numbered
options
0 ( = Nitrogen)
913 Filter Numbered
options
0 ( = Filter off)
913 ASG range Numbered
options
0 ( = 1000 mbar)
914 Master object Numbered
options
0 ( = None)
914 Master object units Numbered
options
59 ( = Pascals)
