UPS: MKD 700 – 3000 VA RT (XL) Operation and Service
Parameter
(Display)
Setting options /
Value ranges
Default
If <enable> is set, the UPS switches directly to the by-
pass mode after being switched on.
If <disable> is set, The UPS does not switch to the by-
pass mode after being switched on but switches to the
by-pass mode when an error or overload occurs.
Short circuit
clearance
[<enable><disable>]
If <enable> is set, the output is reactivated for 4 s
during a short circuit. If the output voltage reaches more
than 50 % of the normal voltage, the UPS device
remains on.
If <disable> is set, the UPS switches the output off after
100 ms in the case of a short circuit.
disable
Bypass voltage
low limit
[<120V>…<215V>]
184V
Bypass voltage
high limit
[<245V>…<276V>]
264V
Bypass frequency
low limit
[<40.0Hz>…<49.5Hz>]
45.0Hz
Bypass frequency
high limit
[<50.5Hz>…<70.0Hz>]
55.0Hz
HE voltage low
limit
[<5%(218.5V)> …<10%(207.0V)>]
5%
(218.5V)
HE voltage high
limit
[<5%(241.5V)> …<10%(253.0V)>]
5%
(241.5V)
HE frequency low
limit
[<5%(47.5Hz)> …<10%(45.0Hz)>]
5%
(47.5Hz)
HE frequency high
limit
[<5%(52.5Hz)> …<10%(55.0Hz)>]
5%
(52.5Hz)
External battery
module
[<0>…<9>]
The selected value indicates the number of external
battery banks. At <0> none are connected.
0
Dry contact signal
input
see below: Configuration of the internal signal
interface.
---
Dry contact signal
output
see below: Configuration of the internal signal
interface.
---
Set running time
Day:0000-9999 Hour:00-23 Minute:00-59 Second:00-59
Settings for the operation hours meter.
Day:0000
Time:
00:00:00
LCD contrast
[<-5>…<+5>]
0
