UPS: MKD 700 – 3000 VA RT (XL) Operation and Service
Parameter
(Display)
Setting options /
Value ranges
Default
The contrast of the LC display can be set from – 5 to +
5.
Configuration of the internal signal interface
The functions of the input for the signal interface can be selected under the
menu item „DRY CONTACT SIGNAL INPUT.”
The functions of the output are likewise under the menu item „DRY CONTACT
SIGNAL OUTPUT.”
The following table declares the possible settings for the interface in this case:
Signal input (DRY-IN):
Description:
Signal input „deactivated“
The signal input is deactivated; a
selection has no effect.
UPS „switched on“ (ON)
The UPS can be switched on by a
remote control.
UPS „switched off“ (OFF)
The UPS can be switched off by a
remote control.
BY-PASS „switched on“ (ON)
The UPS can be switched to the BY-
PASS mode by remote control.
A return out of the BY-PASS mode is
only manually possible; here the
signal must not be on.
Signal output (DRY-OUT):
Description:
Collective alarm (SUMMERY
ALARM)
The signal is on when the UPS is
experiencing an error status.
Autonomous mode (ON BATTERY)
The signal is on when the UPS is in
the autonomous mode.
Low battery bank (BATTERY LOW)
The signal is on when the battery
bank voltage is low.
UPS error free (UPS OK)
The signal is on when the UPS is
error free.
BY-PASS mode (BY-PASS MODE)
The signal is on when the UPS is in
the BY-PASS mode.
