6.14 Starting Characteristics
Function
Parameters
Starting edge
(ALF)
220
The drive acceleration dynamics can be adapted to the sewing machine characteristic (light/heavy).
 High setting value = high acceleration
With a high starting edge setting and, in addition, possibly high braking parameter values on a light machine, the
characteristic may appear coarse. In this case, one should try to optimize the settings.
6.15 Operating hours counter
Function
Parameters
Acoustic signal (operating part)
Service routine for total operating hours
Service routine for operating hours before service
Input of operating hours before service
(AkS)
(Sr6)
(Sr7)
(Sr)
127
176
177
217
The integrated operating hours counter records the time of motor operation. Downtimes are not recorded. Time
recording accuracy is 1ms. There are two ways of operating hours counting.
1. Basic operating hours counting:
217 =0
Operational mode: Operating hours counting
2. Service Hours Monitoring:
217 =>0
Operational mode: Number of operating hours before the next service.
Input of operating hours before the next service.
This value is compared to the operating hours counter.
The input of hours is done in steps of 10. i. e. the lowest display of 001 corresponds to 10 hours
(e. g. 055 = 550 hours).
When the set number of operating hours are reached, the message "C1" will show on the display
after each trimming operation. In addition, the speed indicator blinks on the during operation or
after drive standstill..
176
In this service routine, the total operating hours can be read out according to the procedure
example described below for parameter 177.
177
Display of operating hours since the last service.
Display example of operating hours or hours since the last service and operating hours counter reset.
Display on the control:
 Select parameter 177
 Press the E key

Sr7
 Press the >> key

h t
(hours /thousands letter symbol)
 Press the E key

000
hours /thousands display)
 Press the E key

h h
(hours / hundreds letter symbol)
 Press the E key

000
(hours / hundreds display)
 Press the E key

Min
(minutes letter symbol)
 Press the E key

00
(minutes display)
 Press the E key

SEc
(seconds letter symbol)
 Press the E key

00
(seconds display)
 Press the E key

MS
(milliseconds letter symbol)
 Press the E key

000
(milliseconds display)
 Press the E key

rES
See chapter "Set and Reset Operating Hours Counter"
 Press the E key

The process will be repeated from the hours display.
 Press the P key twice

e.g. 400
(sewing process can be started)
