Efka AB600A5010 - Range of Applications; Use in Accordance with Regulations; Scope of Supply

- AB600A5010 Instruction Manual
- 6 -
1 Range of Applications
The drive is suitable for lockstitch, chainstitch and overlock machines of various manufacturers.
The functions backtacking and stitch compression, are unsupported.
1.1 Use in Accordance with Regulations
The drive is not an independent functional machine. It has been designed for integration into other machines by
trained specialists.
It must not be put into service until the machinery into which it is to be incorporated has been declared in
conformity with the provisions of the EC Directive (Appendix II, paragraph B of the Directive 89/392/EEC and
supplement 91/368/EEC).
The drive has been developed and manufactured in accordance with the relevant EC standards:
IEC/EN 60204-31 Electrical equipment of industrial machines:
Particular requirements for industrial sewing machines, sewing units and sewing systems.
Operate the drive only in dry areas.
ATTENTION
When selecting the installation site and the layout of the connecting cable, the Safety
Instructions must be followed with no exceptions.
Particular attention should be paid to maintaining the proper distance from moving parts!
2 Scope of Supply
Standard Scope of Supply
1
Direct current motor
DC1200 optional DC1250
1
Electronic control
AB600A5010
1
Actuator
EB401
1
Set of accessories (standard)
B156
consisting of:
Plastic bag for B156 + documentation
and
1
Set of accessories
Z74
consisting of:
Plastic bag with connector housing 8 pol.
Molex Minifit and contacts, potential
equalization cord
Option 1
1
Actuator
EB401
and
1
Set of accessories
Z73
consisting of:
Plastic bag with connector housing 8 pol.
Molex Minifit and contacts,pitman rod with
2. ball socket, potential equalization cord
Zusätzliche Optionen
Undertable mounting kit
Z71 AB6..-DC12.. Undertable mounting
Pulse encoder IPG001
Z72 AB6..-DC12.. IPG
NOTE
If there is no metallical contact between drive (motor) and machine head, the potential equalization cord
supplied with the unit is to be wired from the machine head to the terminal provided on the control box!
