- AB AB600A5010 Instruction Manual
- 31 -
7.19 Actuator
7.19.1 Analog actuator
Function
Parameter
Selectable pedal functions
Characteristic of the "analog pedal" EB401
Area for position +1/2 of “analog pedal” in percent
Speed- step distrinution
(-Pd)
(APd)
(plu)
(nSt)
019
026
027
119
The effect of pedal actuation on the drive functions can be set using parameter 019:
019 = 0
Pedal in pos. -1 blocked in the seam. But with pedal in pos. -2 sewing foot lifting is possible in the
seam (function active whenever the light barrier is On).
019 = 1
With pedal in pos. -1 sewing foot lifting is blocked in the seam.
019 = 2
With pedal in pos. -2 thread trimming is blocked (function active whenever the light barrier is On).
019 = 3
The functions pedal in pos. –1and “pedal in pos. –2” are active.
019 = 4
The functions “pedal in pos. –1” and “pedal in pos. –2 are blocked in the seam (function active
whenever the light barrier is On).
019 = 5
Start seam end by placing the portal at -1 (slightly back)
The characteristic of the "analog pedal" can be set using parameter 026:
026 = 0
Analog function off
026 = 1
12-level selected, like prior pedal function of the digital actuator.
026 = 2
Continuously variable (specially for external potentiometer, without
thread trimming function)
026 = 3
24-level
026 = 4
60-level
026 = 5
48-level
026 = 6
40-level, for SOP (standing operation)
119 = 1
119 = 2
119 = 3
Speed- step distrinution linear
Speed- step distrinution low progressiv
Speed- step distrinution high progressiv
8 Signal Test
Function
Parameters
Input and output test
(Sr4)
173
Function test of external inputs, multiple-function key bar and transistor power outputs with connected actuators
(e.g. solenoids and solenoid valves).
8.1 Inputs to the control
Select parameter 173 (OFF is displayed).
Operator control panel: By actuating the key or switche connected to input in1 to in7, the number of the
input actuated appears on the display (i01).
Note: Checking of positions is described in chapter "Displaying the signal and stop positions".
The inputs LSM, HSM and IPG are not checked.
