The light barrier function at the input of socket B18/8 is active only if parameter value 239 = 0.
7.12.1 Speed after Light Barrier Sensing
Light barrier compensating stitches
Number of light barrier seams
Light barrier sensing uncovered/covered
Start of sewing blocked/unblocked with light barrier uncovered
Light barrier seam end with thread trimming On/Off
Speed of the light barrier compensating stitches
After sensing the seam end, the compensating stitches are counted at light barrier speed.
Suspension of the procedure with pedal in pos. 0 (neutral). Interruption of the procedure with pedal in
pos. -2.
The thread trimming operation can be disabled using parameter 133. Stop in the basic position.
Programming of max. 15 light barrier seams depending on the setting of parameter 006 with stop in the
basic position. Thread trimming after the last light barrier seam.
Light barrier sensing uncovered or covered at the seam end can be selected using parameter 131.
Start blockage with light barrier uncovered programmable using parameter 132.
Speed selection pedal controlled / n5 during the light barrier compensating stitches using parameter 192.
7.12.3 Reflection Light Barrier LSM002
Sensitivity setting:
Set minimum sensitivity depending on the distance between light barrier and reflection area (turn potentiometer
as far as possible to the left).
Potentiometer directly on the light barrier module
Mechanical orientation:
Orientation is facilitated by a visible light spot on the reflection area.
