- AB600A5010 Parameter List
- 52 -
12.2 Technical level (Code no. 1907)
Parameters
Designation
Unit
Max
Min
Preset
Ind.
100 SSc
Number of softstart stitches
Stitches
254
0
2
110 n1
Positioning speed for threading (mode 66)
RPM
390
70
200
111 n2
Upper limit setting range of the maximum speed
RPM
9900
n2_
5000
114 n5
Speed after light barrier sensing
RPM
9900
200
1200
115 n6
Softstart speed
RPM
9900
70
500
116 n7
Trimming speed
RPM
700
70
200
118 n12
Automatic speed for stitch counting
RPM
9900
400
3500
119 nSt
Speed stage graduation
1 = Linear
2 = Slightly progressive
3 = Highly progressive
3
1
121 n2
Lower limit setting range of the maximum speed
RPM
n2_
200
400
122 n9
Limited speed n9
RPM
9900
200
2000
128 ASd
Start delay, when command “start” is given by covering
the light barrier (see parameter 129)
ms
2000
0
0
129 ALS
Machine start by covering the light barrier (only in conjunction with
parameter 132 = 1)
0 = Function Off
1 = Light barrier covered  pedal forward (>1) machine run pedal
controlled.
2 = Pedal forward (>1)  light barrier covered machine run  pedal
controlled.
3 = Light barrier covered  machine run at automatic speed n12
(without pedal)
4 = Pedal forward (>1)  light barrier covered machine run pedal
controlled.
5 = Light barrier covered  machine run at automatic speed n12
(without pedal)
Attention! If 129 = 3, the machine starts immediately after covering
the light barrier without influence by the pedal! It can be stopped only
by uncovering the light barrier or by machine run blockage!
If machine run blockage is disabled, the machine starts immediately
even if the light barrier is still covered!
6 = The same as 3, run without pedal when covering the light
curtain, however start up only when FI is lowered.
3
0
0
130 LSF
Light barrier filter for knitted fabrics
1
0
0
131 LSd
0 = Light barrier sensing “covered”
1 = Light barrier sensing uncovered
1
0
1
132 LSS
0 = Machine start possible with light barrier uncovered or covered.
1 = Machine start blocked with light barrier uncovered if parameter
131 = 1.Machine start blocked with light barrier covered,
1
0
1
133 LSE
Thread trimming operation, when completing the seam after light
barrier sensing On/Off
1
0
1
134 SSt
Softstart On/Off
1
0
0
140 dnE
Delay of seam end with pedal in pos. -2
ms
2550
0
0
141 SGn
Speed status for the seam with stitch counting
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111)
1 = Fixed speed (Parameter 118) without influence by the pedal
(machine stop by pressing the pedal to the basic position)
2 = Limited speed controllable by the pedal up to the set limit
(Parameter 118)
3 = At fixed speed (Parameter 118) can be interrupted by full
heelback -2
4 = At fixed speed (Parameter 110) can be interrupted by full
heelback -2
4
0
0
142 SFn
Speed status for the free seam and for the seam with light barrier
0 = Speed controllable by the pedal up to the set maximum speed
(Parameter 111)
1 = Fixed speed (Parameter 118) without influence by the pedal
(machine stop by pressing the pedal to the basic position)
2 = Limited speed controllable by the pedal up to the set limit
(Parameter 118)
3 = At fixed speed (Parameter 118) can be interrupted by full
heelback (only for seams with light barrier).
3
0
0
153 brt
Braking power at machine standstill
50
0
15
