Efka AB600A5010 - Operator Level Parameters (Continued)

- AB600A5010 Parameter List
- 51 -
Parameters
Designation
Unit
Max
Min
Preset
Ind.
019 -Pd
0 = Pedal in pos. -1 blocked in the seam. But with pedal in pos.
-2 sewing foot lifting is possible in the seam (function active
whenever the light barrier is On)
1 = With pedal in pos. -1 sewing foot lifting is blocked in the seam.
2 = Pedal in pos. –2, thread trimming disabled. (Function only if
parameter 009 = 1)
3 = Pedal in pos. –1 and –2 enabled in the seam.
4 = Pedal -1 and -2 locked in the seam (function only when
parameter 009 =1)
5 = Start seam end by with pedal -1
5
0
3
023 AFL
Automatic sewing foot lifting with pedal forward at the seam end, if
light barrier or stitch counting is On.
0 = Automatic foot lifting off
1 = Automatic foot lifting On
1
0
1
025 tFS
Start counting (pa. 157) for thread tension release at the start of the seam
0 = Start counting at the start of the seam
1 = Start counting when the light barrier is covered
1
0
1
026 APd
Characteristic of the "analog pedal"
0 = Analog function off
1 = 12-level, like previous pedal function
2 = continuously variable
3 = 24-level
4 = 60-level
5 = 48-level
6 = 48 level / standing operation (SOP; foot control 304)i
6
0
4
027 plu
Area for setting + 1/2 of the analog pedal in percent
80
10
30
041 EZP
Special pedal function Single stitch / Full stitch
0 = Function Off
1 = Single stitch (assuming needle up to needle down). Afterwards
alas a complete hand wheel rotation in speed n9)
2 = Full stitch (a complete hand wheel rotation in speed n9)
3 = Speed limitation up to F-042
2
0
0
042 GrP
Pedal travel forwards for detection of the special pedal
function
%
100
0
40
049 KML
Coupling motor running (o) signal (F-290=7)
=0 OFF
=1 Coupling with pedal Mi1 & pedal Mi2 in the seam
=2 Coupling with pedal Mi1 & pedal Mi2 outside of the
seam
=3 Coupling with pedal Mi1 & pedal Mi2 in and outside of
the seam
3
0
0
049 KML
051 dPd
Time for detection of the special pedal function
ms
2550
0
100
082 DDr
Suck stitches to waste
Stitches
254
0
25
083 tDr
Time sucking waste
ms
5000
0
0
084 Mle
Stitches for motor ECO On
Stitches
254
0
5
085 Mla
Stitches for motor ECO runs down
Stitches
254
0
5
088 kla
Stitches for clamping the seam start (mode 68)
Stitches
20
0
3
