9 Table of Machine Functions and Adapter Cords
ATTENTION
Before switching functional sequences, detach cables from the inputs and outputs! It must be
absolutely certain that for the functional sequence to be changed the machine provided has
been installed! Then proceed with the setting using parameter 290!
Setting the functional sequence using parameter 290
Functions / Outputs
Power transistors 
M1
M2
FL
Mode
Function / Machine
B3/6
B3/7
B3/8
0
Lockstitch
FA1+2
ML
FL
5
Chainstitch: parallel sequence
AH
ML
FL
6
Chainstitch: tape cutter/fast scissors
AH1
AH2
FL
7
Overlock
M1
M2
FL
Explanation of letter symbols of the above table and chapter ”Timing Diagrams“
Ausgänge
Ausgänge
AH
Tape cutter
FL
Sewing foot lifting
AH1/AH2
Fast scissors
ML
Machine running
FA1+2
Thread trimmer pos. 1...2
Note: The outputs M1, M2 and M3 can be used with other functions by changing the settings of parameters
382, 383 and 385, depending on the signal sequence or signal duration required for each machine.
*) The signal issued at this output is inverted!
