Efka AB600A5010 - Tape Cutter and Fast Scissors; Seam with Stitch Counting

- AB AB600A5010 Instruction Manual
- 25 -
7.8 Tape Cutter/Fast Scissors (Modes 6/7)
The signal tape cutter/fast scissors is issued only at the seam end. Furthermore, the manual tape cutter/fast
scissors function can be set. See also chapter "Manual Tape Cutter/Fast Scissors".
Function
Parameters
Tape cutter at the seam end On/Off
014
7.8.1 Tape Cutter/Fast Scissors in Mode 7
The signal tape cutter/fast scissors can be set separately for start and end counting. See also chapter
"Manual Tape Cutter/Fast Scissors ".
Function
Control
Tape cutter/Fast scissors at the start of the seam On
Tape cutter/Fast scissors at the seam end On
Tape cutter/Fast scissors at the start and at the end of the seam On
Tape cutter/Fast scissors at the start and at the end of the seam Off
LED-segment 3 On
LED-segment 4 On
LED-segment 3 and 4 On
LED-segment 3 and 4 Off
Key + (S3)
Output and Times for Tape Cutter
Function
Parameter
Delay time for output M1 (B3/6) tape cutter AH
ON period for output M1 (B3/6) tape cutter AH
(kd1)
(kt1)
280
281
 Parameter 232 must be set at "0" (tape cutter function).
 The delay time for the tape cutter is usually set at "0".
Output and Times for Fast Scissors
Function
Parameter
Delay time for output M1 (B3/6) fast scissors AH1
ON period for output M1 (B3/6) fast scissors AH1
Delay time for output M2 (B3/7) fast scissors AH2
ON period for output M2 (B3/7) fast scissors AH2
(kd1)
(kt1)
(kd2)
(kt2)
280
281
282
283
 Parameter 232 must be set at "1" (fast scissors function).
 The delay times for "fast scissors" are usually set at "0".
7.9 Manual Tape Cutter/Fast Scissors
Upon pressing an external key depending on the pre-selection of parameters 240...246, the tape cutter or fast
scissors can be enabled anywhere in the seam or at standstill.
See also chapter "Connection Diagram" in the List of Parameters!
7.10 Seam with Stitch Counting
Function
Parameters
Stitch counting On/Off
(n7)
015
7.10.1 Number of Stitches for a Seam with Stitch Counting
Function
Parameters
Number of stitches for the seam with stitch counting
(Stc)
007
The number of stitches for stitch counting can be set directly on the control with parameter 007.
