Efka AB600A5010 - Modes 5, 6, 7: Unlocking the Chain

- AB600A5010 Parameter List
- 41 -
Mode 5, 6 or 7 (function “unlocking the chain”)
Mark
Function
Parameter
Control
FAm
drE
Frd
in1
Mode 5
Direction of motor rotation
Reverse motor rotation
Basic position 2
Thread trimmer *)
Assign the function “unlocking the chain” to
input in1
Clockwi
se
On
On
290 = 5
161 = 0
182 = 1
240
Key >>
n1
n2
Positioning speed
Maximum speed
110
111
ird
drd
t3
Number of reversing increments
Switch-on delay of reverse motor rotation
Start delay from lifted sewing foot
180
181
202
*) When unlocking the chain, the function “thread trimmer” is suppressed!
*) When unlock ing the chain, the functions “stitch condensing” and “thread trimmer” are suppressed!
