14
CAUTION: Verify the condensation drain hose is properly configured ensuring proper
drainage as shown in the images below. Improper drainage may cause water damage to the
home and property.
Proper
drainage
Upward turns
anywhere in the length
of the drain hose will
cause water traps.
Kinks in the drain
hose will cause water
traps.
Do not place
containers at the end
of the drain hose that
could prevent proper
drainage.
