EG4 9K AC MINI-SPLIT - 1 Technical Specifications

1
1. TECHNICAL SPECIFICATIONS
ELECTRICAL 9K SYSTEM 12K SYSTEM
RATED VOLTAGE
115VAC 115VAC
RATED CURRENT - COOLING
5.97A 8.45A
RATED CURRENT - HEATING
6.37A 7.47A
INPUT POWER
190 – 1,000W 190 – 1,050W
FREQUENCY
60Hz
MINIMUM CIRCUIT AMPACITY
19.05A
MAXIMUM BREAKER SIZE
20A
MAXIMUM STARTING CURRENT
4A
RATED COOLING
NOMINAL CAPACITY
9,000 BTU/h 12,000 BTU/h
CAPACITY RANGE
3,000 – 10,000 BTU/h 3,000 – 13,000 BTU/h
EER
13.23 12.5
SEER2
29.5 28.5
RATED HEATING
NOMINAL CAPACITY
9,700 BTU/h 12,000 BTU/h
CAPACITY RANGE
3,000 – 11,000 BTU/h 3,000 – 13,000 BTU/h
HSPF2
10.7 11.3
SYSTEM DATA
DESIGN PRESSURE (PSIG)
<651 PSI
REFRIGERANT
R410A/45.86 oz. (1.35L)
PRE-CHARGED REFRIGERANT LINE
16.4 ft. (5m)
CHARGE REQUIRED PER ADDITIONAL FT
0.2 oz. (6ml)
LIQUID VALVE DIAMETER
0.25 in. (6.35mm)
GAS VALVE DIAMETER
0.5 in. (12.7mm)
MAX REFRIGERANT PIPE LENGTH
49 ft. (15m)
MAX ELEVATION BETWEEN UNITS
26 ft.
COMPRESSOR SPECIFICATIONS
TYPE
2 × Rotary
INPUT POWER
190 – 1,000W 190 – 1,050W
RATED LOAD AMPERAGE (RLA)
3.6A
