Horizontal Airflow (Left/Right) Adjustment:
The angle of the horizontal louver must be set manually. Move the deflector rod, located on the
underside of the unit, by pushing the tab manually left or right to adjust the airflow from side to
side as desired.
8.6 INDOOR UNIT DISPLAY
The indoor unit LED display is equipped to display information from different models. Not all
the features listed below will be equipped on the unit purchased. Please check the indoor unit
LED display window of the unit purchased to see which of these features the unit has.
The light is displayed when the
photovoltaic controller is working on
hybrid units. (Not available on this unit).
This will display when the Wireless
Control feature is activated (some units).
When connected to AC power, the light
displays white.
This is the temperature display and will
also display operational features and
error codes. See “Section 11.3” for a list
of error codes.
Will display when the unit is defrosting.
