Throttle Max Power (W)
PAS Max Power (W)
Motor Phase Current (A)
Regen Ratio (%)
Throttle Max Speed (km/h)
Pas Max Speed (km/h)
Battery Current Limit (%)
Field Weakening (Max 50%)
Power lock pin on the EggRider display should be left free.
ASI BAC500/800 pin # ASI pin function EggRider pin function
13 +12V P+
16 Gnd GND
17 Display Rx TxD
18 Display Tx RxD
21 Key out - External switch -
22 Key in - External switch -
Last update: June 30, 2021
6.7 ASI - Accelerated Systems Inc settings
- 71/89 -
