Eizo ColorEdge CS2410 User Manual

17
Chapter 3 Advanced Adjustments/Settings
Function Settings Description
Brightness 0% to 100% The screen brightness is adjusted by changing the brightness
of the backlight (light source from the LCD back panel).
Temperature Native
4000 K to 10000 K
sRGB
User
The color temperature can be adjusted.
The color temperature is used to express the chromaticity of
"White". The value is expressed in degrees "K" (Kelvin).
The screen becomes reddish at a low color temperature, and
bluish at a high color temperature, like the temperature of a
ame.
Specify a color temperature in units of 100 K, or select a
standard name.
Note
• When you select "Native", the original color of the LCD panel
(Gain: 100 % for each RGB) is displayed.
• "Gain" allows you to perform more advanced adjustment.
When gain is changed, the color temperature is changed to
"User".
• The gain preset values are set for each color temperature
setting value
.
Gamma 1.6 to 2.7
sRGB
Adjust the gamma.
The brightness of the monitor varies depending on the input
signal, however, the variation rate is not simply proportional
to the input signal. The control performed to keep the balance
between the input signal and the brightness of the monitor is
called "Gamma correction".
Set the gamma, or select a standard name.
Color Gamut Native
sRGB
Set the color reproduction area (color gamut).
"Color Gamut" is the range of colors that can be represented.
Multiple standards are dened.
Note
• Select "Native", to display the original color gamut of the
monitor.
• The method of displaying colors outside the monitor's
displayable range within the dened color gamut can be set.
For more information, see “Clipping” (page 18).
