Eizo ColorEdge CS2410 User Manual

39
Chapter 6 Reference
6 -7. Specications
LCD Panel Type IPS (Anti-Glare)
Backlight Wide color gamut LED
Size 61.1 cm (24.1 inch)
Resolution 1920 dots x 1200 lines
Display Size (H x V) 518.4 mm x 324.0 mm
Pixel Pitch 0.270 mm x 0.270 mm
Pixel Density 94 ppi
Display Colors Approx. 16.77 million colors (8 bit colors)
Viewing Angle (H x V, typical) 178˚ / 178˚
Contrast Ratio (typical) 1000 : 1 (When "DUE Priority" setting is "Brightness")
Response Time (typical) Gray-to-gray: 14 ms
Color Gamut Display (typical) sRGB coverage 100%, NTSC ratio 79%
Video Signals Input Terminals
DisplayPort 1.1a (HDCP 1.3 compatible) x 1,
HDMI (HDCP 1.4, Deep Color compatible)
*1
x 1,
DVI (Single Link, HDCP 1.4 compatible) x 1
*1 Not compatible with HDMI CEC function (mutual control
function).
Horizontal scan frequency DisplayPort: 26 kHz to 78 kHz
HDMI (Video mode): 15 kHz to 68 kHz
HDMI (PC mode): 26 kHz to 78 kHz
DVI: 26 kHz to 78 kHz
Vertical scan frequency DisplayPort: 23 Hz to 63 Hz (For 720 x 400: 69 Hz to 71 Hz)
HDMI (Video mode): 23 Hz to 61 Hz
HDMI (PC mode): 23 Hz to 63 Hz
HDMI (for 720 x 400): 69 Hz to 71 Hz
DVI: 23 Hz to 63 Hz (For 720 x 400: 69 Hz to 71 Hz)
Frame Synchronization mode 23.75 Hz to 30.5 Hz, 47.5 Hz to 61.0 Hz
Dot clock (Max.) 164 MHz
USB Port
Upstream USB Type-B (USB3.1 Gen1) x 1
Downstream USB Type-A (USB3.1 Gen1) x 3
(The "CHARGE" port supports quick recharging)
Standard USB Specication Revision 3.1 Gen 1
Communication Speed
5 Gbps (super), 480 Mbps (high), 12 Mbps (full), 1.5 Mbps (low)
Supply Current Downstream USB Type-A (USB3.1 Gen1): Maximum 900 mA per port
USB Type-A ("CHARGE" Port): Normal: Maximum 1500 mA
per port, Charging Only: Maximum 2100 mA per port
Power Input 100-240 VAC ±10 %, 50/60 Hz 0.60 A to 0.30 A
Maximum Power Consumption 57 W or less
Power Save Mode 0.7 W or less (this applies when the OS turns to sleep mode or
when the monitor's power off setting is activated, if the monitor
has DisplayPort input signal only, "Auto Input Detection" is set
to "Off", no USB device is connected, and "USB CHARGE
Port" is set to "Normal")
Standby Mode 0.6 W or less (when "Auto Input Detection" is set to "Off",
no USB device is connected, "USB CHARGE Port" is set to
"Normal", and "DP Power Save" is set to "On")
