Chapter 6
Reference
6-2. Attaching the Optional Arm
An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our
web site for the corresponding optional arm (or optional stand). www.eizoglobal.com
Attention
• When attaching an arm or stand, follow the instructions of their User's Manual.
• When using another manufacturer's arm or stand, conrm the following in advance and select one conforming
to the VESA standard. Use the VESA mounting screws supplied with this product when attaching the arm or
stand.
- Clearance between screw holes: 100 mm x 100 mm
- External dimensions of the VESA mount section of the arm or stand: 122 mm x 122 mm or less
- Plate thickness: 2.6 mm
- Must be strong enough to support weight of the monitor unit (excluding the stand) and attachments such as
cables.
• When using an arm or stand, attach it to meet the following tilt angles of the monitor.
- Up 45˚, down 45˚
• Connect the cables after attaching an arm or stand.
• Since the monitor and arm or stand are heavy, dropping them may result in injury or equipment damage.
• When installing the monitor in portrait mode, turn the monitor screen 90˚ in clockwise direction.
Attaching the Optional Arm (or Optional Stand)
1.
Attach the arm or stand to the monitor.
Use the VESA mounting screws supplied with this product when attaching the arm or stand.
Attaching the Original Stand
1.
To prevent damaging the panel surface, lay the monitor with its panel surface
facing down on a soft cloth spread on a stable surface.
2.
Removethexingscrewsontheoptionalarm(oroptionalstand),anddetach
the optional arm (or optional stand).
3.
Attach the original stand.
Insert the four tabs on the stand into the square holes on the back panel (1) and slide the stand
towards the upper portion of the monitor until it makes a clicking sound (2).
(1)
(2)(2)
To Next Page
