10
Chapter 1 Introduction
●
Rear
16
17
15
10 11 12 13 14
10. Main power switch Turns the main power on or off.
11. Power connector Connects the power cord.
12. Input signal connectors Left: DVI-I connector / Center: HDMI connector / Right: DisplayPort connector
13. USB upstream port
Connects the USB cable to use the software that needs USB connection, or to use
USB hub function (page 51).
14. USB downstream port Connects a peripheral USB device.
15. Stand
*2
Used to adjust the height and angle of the monitor screen.
16. Security lock slot Complies with Kensington’s MicroSaver security system.
17. Cable holder Covers the monitor cables.
*2 An optional arm (or an optional stand) can be attached by removing the stand section (see “8-1. Attaching the Optional Arm”
(page 50)).
To Next Page
