Chapter2AdjustingScreens
●
To remove ickering or blurring <Phase>
Procedure
1. Choose <Phase> from the <Screen> menu, and press
.
The <Phase> menu appears.
2. Adjust the phase with or to minimize ickering or blurring.
3. Press
to exit the adjustment.
When vertical bars appear on the screen after adjustment, go back to “To eliminate vertical bars <Clock>”.
(Clock → Phase → Position)
Attention
• Flickering or blurring may not be eliminated depending on your PC or graphics board.
●
To correct the screen position <Hor.Position> <Ver.Position>
Note
• Since the number of pixels and the pixel positions are xed on the LCD monitor, only one position is provided to
display images correctly. The position adjustment is made to shift an image to the correct position.
Procedure
1. Choose <Hor.Position> or <Ver.Position> from the <Screen> menu, and press
.
The <Hor.Position> or <Ver.Position> menu appears.
2. Adjust the position with or .
3. Press
to exit the adjustment.
4. Close Pattern 1.
