Chapter1Introduction
●
Stand installation (LaidBack Stand)
This product can be adjusted to angles of 15°, 25°, 35°, 45°, 55°, and 65°.
CAUTION
Do not use the stand in its packaged state.
Thestandisfoldedwhenitispackagedforshipment.Usingitinthisstatewill
makethemonitorunstable,potentiallyresultinginitfallingoverandcausing
injuriesorequipmentdamage.Whenusingthestand,unfoldittoatleast15°and
setitupcorrectly.
●
Folding the stand (LaidBack Stand)
Perform the following procedure to fold the stand when re-packing the monitor.
1.
Lay the LCD monitor on a soft cloth spread over on a stable surface with the
panel surface facing down.
2.
Press the lever up and move the stand forward to its minimum angle of 15°.
3.
Keeping the lever in the up position, press the lock release button.
The stand will fold into its packaging position.
Lockreleasebutton
Lever
Max.65º
Min.15º
