Eizo FLEXSCAN T1751

39
Chapter7Reference
7-5. Preset Timing
The following table shows factory preset analog signal timing:
Attention
• Display position may be deviated depending on the PC connected, which may require screen adjustment using
Adjustment menu.
• If a signal other than those listed in the table is input, adjust the screen using the Adjustment menu. However, screen
display may still be incorrect even after the adjustment.
• When interlace signals are used, the screen cannot be displayed correctly even after screen adjustment using the
Adjustment menu.
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640×480 VGA 25.18 31.47 59.94 Negative Negative
640×480 VESA 31.50 37.86 72.81 Negative Negative
640×480 VESA 31.50 37.50 75.00 Negative Negative
720×400 VGATEXT 28.32 31.47 70.09 Negative Positive
800×600 VESA 36.00 35.16 56.25 Positive Positive
800×600 VESA 40.00 37.88 60.32 Positive Positive
800×600 VESA 50.00 48.08 72.19 Positive Positive
800×600 VESA 49.50 46.88 75.00 Positive Positive
1024×768 VESA 65.00 48.36 60.00 Negative Negative
1024×768 VESA 75.00 56.48 70.07 Negative Negative
1024×768 VESA 78.75 60.02 75.03 Positive Positive
1152×864 VESA 108.00 67.50 75.00 Positive Positive
1280×960 VESA 108.00 60.00 60.00 Positive Positive
1280×1024 VESA 108.00 63.98 60.02 Positive Positive
1280×1024 VESA 135.00 79.98 75.03 Positive Positive
