ELAN HOME SYSTEMS TS10 User’s Guide
© ELAN Home Systems 2010 | All rights reserved.
Page 48
Media (Continued)
Source Samples
The following images are to provide examples only of control pages for various sources.
Your actual source controls may look different.
This example is a cable box with DVR capabilities. Note the “MAIN” and “DVR” tabs,
indicating two pages of controls for the source.
Figure 3-70:
Media Page
Example: Cable Box
Main Page
Figure 3-71:
Media Page
Example: Cable Box
DVR Page
