ELAN HOME SYSTEMS TS7 User’s Guide
© ELAN Home Systems 2010 | All rights reserved.
Page 36
ELAN DT22 / DT11
The DT22 is a Dual AM/FM Sirius Ready Tuner with 2-way feedback capabilities. The DT11
is a single AM/FM Sirius Ready Tuner with 2-way feedback capabilities. The DT22 and
DT11 display RDS (Radio Data System) information if available. Each tuner has 396
presets.
The look and operation of the AM/FM tuner and the Sirius tuner is different so each will be
covered separately in this manual.
AM/FM Tuner
Favorites Tab
The initial screen displayed when the AM/FM tuner is selected is the FAVORITES tab. This
tab displays preset radio stations, enabling a station to be tuned in with the press of a
button. The FAVORITES tab shows both AM and FM presets on the same page.
The frequency for the currently selected radio station is displayed at the top of the screen.
If RDS information (Genre, Artist, Track Title, etc.) is available for the station it is shown
below it.
If the currently selected station is one of the presets the preset button will also be
highlighted. Use the BAND button at the upper right to switch between AM and FM tuning.
Figure 3-50:
Media Page
DT22 AM/FM
Favorites Tab
