8.4 CHARGING CYCLE FUNCTIONAL CONTROL
Follow the diagram below (starting from the top left corner) to solve or identify the problem.
IS THE GREEN
LED ON?
CHARGING CYCLE
COMPLETED
IS THE RED
LED ON?
CLEAN THE ELECTRICAL
CONTACTS ON THE
TRANSMITTER AND
CHARGING SYSTEM
IS THE RED
LED ON?
CHECK THE CHARGING
SYSTEM'S POWER
SUPPLY
CONTACT
SERVICE.
IS THE RED
LED ON?
CONTACT
SERVICE.
CHARGING CYCLE
COMPLETED
WAIT UNTIL
CHARGING IS
COMPLETE
IS THE RED LED
OFF AND THE
GREEN LED ON?
HAVE MORE THAN 4
HOURS PASSED ?
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO NO
