93 / EN
User Menu
Selecting the type of time schedule: free or pre-set
DHW
Scenario
Free
55°
55°
0 2 4 6 8 10 12 16 20 14 18 22 24
Sunday
Monday
Tuesday
55°
Save
Fig. 33
– Press the selector
to enter the edit mode.
– Select “Free” to proceed with the creation of a customised
weekly schedule, otherwise select one of the pre-set pro-
files:
– "Family"
– "No lunch"
– "Midday"
– "Always active"
– "GREEN"
– Press the selector
to confirm “Scenario”.
– Turn the selector
to move to the selection of the day
of the week to be scheduled.
Selecting the day of the week
DHW
Scenario
Free
55°
55°
0 2 4 6 8 10 12 16 20 14 18 22 24
Sunday
Monday
Tuesday
55°
Save
Fig. 34
– Turn the selector
to scroll the days of the week. A pre-
view of the current time schedule will be displayed.
– Press the selector
to select the day.
– In this way you can define the time slot for the selected
day.
Defining the time slot
DHW
Scenario Free Sunday
Start 09:00
35°
,0
End 15:00
35,0° 55,0° 35,0° 55,0°
0 2 4 6 8 10 12 16 20 14 18 22 24
Fig. 35
Once the day of the week has been selected, the time slot
scheduling page opens up.
– Turn the selector
to change the “Start” time.
– Press the selector
to confirm.
DHW
Scenario Free Sunday
Start 09:00
35°
,0
End 15:00
35,0° 55,0° 35,0° 55,0°
0 2 4 6 8 10 12 16 20 14 18 22 24
Fig. 36
– Turn the selector
to change the temperature of the
corresponding time slot. You can select the set-point
temperature by choosing between two values: com-
fort or reduced.
– Press the selector
to confirm.
