GENERAL
11/56
EN
22
21
20 19 18 17 15
1311 12
16
14
11
Combustion head
12
Burner fixing bolt
13
Burner flange (supplied)
14
7 pin plug
15
Electric motor for pump and fan
16
Capacitor
17
Extended pressure port
18
Burner base
19
Oil pressure regulator
20
Fuel-oil pump
21
Solenoid valve
22
Ignition transformer
Fig. 3
