performed, it makes it impossible to start the module without performing a new
calibration procedure.
● display of the module's current status, which can be:
◦ OFF: module off and uninitialized
◦ READY: module ready (can only be started in case of performed calibration)
◦ ON : module running
◦ ERROR: module in the emergency state , associated with the possible
exceeding of the parameters "Input min" or "max Input" as shown previously
◦ CALIB. INIT: initial state of the calibration procedure
◦ CALIB. STEP 1: phase 1 of the calibration procedure
◦ CALIB. STEP 2: phase 2 of the calibration procedure
◦ CALIB. STEP 3: phase 3 of the calibration procedure
◦ CALIB. STEP 4: phase 4 of the calibration procedure
Some notes on the calibration procedure : It is performed by bringing the system to the
current target temperature by performing an ON / OFF output for heating (temperature
lower than the current target → heating on, temperature above the target → heating off).
Each of the stages, therefore, will end when the current temperature will exceed the set
target. STEP 4 After the procedure is complete , the module will automatically enter the
ON state. Some tips:
● perform calibration by setting a target temperature close to the actual working
temperature
● depending on the system to adjust, the procedure can take several minutes (if not
tens of minutes)
