In this system environment, you can set all the parameters of the axes .
In the chart , the three axes are identified by a letter at the end of the description of the
parameters with the following combination:
● chain axis → letter x
● blades axis → letter y
● rollers axis → letter w
The parameters on the axis page represent a subset of those in this table, with the
following combination:
● "Acceleration time" → T.Acc.A.<letter> e T.Acc.I.<letter>
● "Deceleration Time"→ T.Dec.A.<letter> e T.Dec.I.<letter>
● “Quote loop” → Q.Giro <letter>
● "Number impulses"→ Nr Imp <letter>
● "Speed calibration"→ VeFCTar <letter>
● “Quote calibration” → Q.Tarat.<letter>
● “Motor direction” → Dir.Enc.<letter>
● “Speed movements” → not corresponding to any of the parameters in the table.
The remaining parameters are reserved and SHOULD NOT BE CHANGED.
3.16 – TEST I/O
The functionality of the tests are divided into four main categories:
● CONFIGURATION: information about the circuit boards
