USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
DIGITAL OUTPUTS - EC7 DIO_022 – SLOT A
POLE
N°
DESCRIPTION
TEST I/O
21
Printer control
1
22
Exit belt control
2
23
Heater relay for jaws 1-2
3
24
Heater relay for jaws 3-4
4
25
Heater relay Rollers
5
26
Labeler control
6
27
Nebulizer control
7
28
Available
8
29
Input +24V - supply outputs
30
Outputs supply reference
DIGITAL OUTPUTS - EC7 DIO_022 – SLOT A
POLE
N°
DESCRIPTION
TEST I/O
31
Available
9
32
Available
10
33
Available
11
34
Available
12
35
Available
13
