USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
36
Available
14
37
Available
15
38
Available
16
39
Input +24V - supply outputs
40
Outputs supply reference
ANALOG I/O BOARD – EC7AI_041 - SLOT E
POLE
N°
DESCRIPTION
1
Do not use
2
ANALOG INPUT 1 – Cut and weld temperature 4-20 mA
3
Do not use
4
Do not use
5
Do not use
6
ANALOG INPUT 2 – Cut and weld temperature 3/4 4-20 mA
7
Do not use
8
Do not use
9
+ 5V (supply to potentiometer)
10
+0V
ANALOG I/O BOARD – EC7AI_041 - SLOT E
POLE
N°
DESCRIPTION
