USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
11
Do not use
12
ANALOG INPUT 3 – Rollers temperature 4-20 mA
13
Do not use
14
Do not use
15
ANALOG INPUT 4 –POTENTIOMETER- SPEED ADJ.
16
Do not use
17
Do not use
18
Do not use
19
+ 5V (supply to potentiometer)
20
+0V
ANALOG I/O BOARD – EC7AI_041 - SLOT E
POLE
N°
DESCRIPTION
21
ANALOG INPUT 5 – VOLTAGE 0-10V – Available
22
ANALOG INPUT 5 – VOLTAGE 4-20 mA – Available
23
ANALOG INPUT 5 – VOLTAGE PT100 – Available
24
ANALOG INPUT 5 – VOLTAGE PT100 – Available
25
ANALOG INPUT 6 – VOLTAGE 0-10V – Available
26
ANALOG INPUT 6 – VOLTAGE 4-20 mA –Available
27
ANALOG INPUT 6 – VOLTAGE PT100 – Available
28
ANALOG INPUT 6 – VOLTAGE PT100 – Available
51
