elco TOP7 - Page 52

DmPackagingGroup
s.r.l
StradadelCascinotto156,
10156,Torino(TO)-Italy
Tel:011.99.10.455
e-mail:
info@dmpackagingroup.com
USER MANUAL TOP7
SW: EFPLCAC0
Date:
15/02/2016
29
ANALOG OUTPUT +/- 10V – X– Available
30
+0V
ANALOG I/O BOARD – EC7AI_041 - SLOT E
POLE
N°
DESCRIPTION
31
ANALOG INPUT 7 – VOLTAGE 0-10V – Available
32
ANALOG INPUT 7 – VOLTAGE 4-20 mA – Available
33
ANALOG INPUT 7 – VOLTAGE PT100 – Available
34
ANALOG INPUT 7 – VOLTAGE PT100 – Available
35
ANALOG INPUT 8 – VOLTAGE 0-10V – Available
36
ANALOG INPUT 8 – VOLTAGE 4-20 mA – Available
37
ANALOG INPUT 8 – VOLTAGE PT100 – Available
38
ANALOG INPUT 8 – VOLTAGE PT100 – Available
39
ANALOG OUTPUT +/- 10V – X– Available
40
+0V
Connections CAN TOP 7 – HDT
TOP 7
(DB9)
DESCRIPTION
HDT
(RJ45)
1
CAN H
1
5
GND
3
6
CAN L
2
52
