21
Details of Elcometer offices around the world are given on the outside cover of
these Operating Instructions. Alternatively visit the Elcometer website,
www.elcometer.com
10 TECHNICAL SPECIFICATION
Table dimensions: 200 mm x 100 mm
(7.9" x 3.9")
Stroke length: 20 mm to 180 mm
(0.8" to 7")
Minimum sample size (vacuum mounting) 140 mm x 80 mm
(5.5" x 3.1")
Force exerted by tool on specimen: 6 N to 123 N
d
*Compressed air pressure (maximum): 9 bar (135 psi)
Dimensions: 630 mm x 310 mm x 400 mm
(25" x 12" x 18")
Weight: 45 kg (20lb)
*Guaranteed noise pressure falls below 70dBA
d. To obtain the maximum force of 123 N, the compressed air supply to the tester must
be a minimum of 7 bar.
Op_1535_01 A5.fm Page 21 Wednesday, August 8, 2007 3:59 PM
