20
8 AIR PRESSURE/FORCE
The table below shows the relationship between the air pressure shown on the
pressure gauge and the force exerted by the tool on the specimen.
9 MAINTENANCE
The Elcometer 1535 Multi Function Scratch Tester is designed to give many
years reliable service under normal operating and storage conditions.
The table must be kept clean and free from knocks. Ensure supply is
disconnected and ventilated to the atmosphere during cleaning. Any
deformation of the surface of the table will adversely affect the quality of the
scratches, especially cross cut scratches.
The Elcometer 1535 Multi Function Scratch Tester does not contain any internal
user-serviceable components. In the unlikely event of a fault, the Elcometer
1535 Multi Function Scratch Tester should be returned to your local Elcometer
supplier or directly to Elcometer.
Pressure
(bar)
Force
(kg)
Pressure
(bar)
Force
kg)
0.2 6 2.4 51
0.4 12 2.8 59
0.6 16 3.2 67
0.8 20 3.6 75
1 24 4.0 83
1.2 27 4.4 91
1.4 31 4.8 99
1.6 35 5.2 107
1.8 39 5.6 115
2 43 6.0 123
