12 TECHNICAL SPECIFICATION
Range: 0.15 mm to 25.4 mm (0.006" to 1.000")
Resolution: 0.002 mm (0.0001")
Accuracy: ±0.002 mm (±0.0001"), depends on material and conditions
Sound-velocity range: 1250 m/s to 10 000 m/s (0.0492 in/µs to 0.3937 in/µs)
Weight: 295 g (10 oz) including batteries
Size: 63.5 mm x 120.6 mm x 31.5 mm (2.5" x 4.5" x 1.24")
Operating temperature: -30°C to 50°C (-20°F to 120°F) - depending upon climatic conditions
Case: Extruded aluminium body, Nickel plated aluminium end caps
Battery type: 2 x LR6 (AA), alkaline dry batteries or rechargeable
a
equivalents
Battery life: 200
b
hours continuous (alkaline dry batteries)
a. Rechargeable batteries can be used if they are charged outside the gauge.
b. Battery life is reduced to approximately 120 hours when using rechargeable batteries. Follow the instructions
provided by the battery manufacturer when charging and disposing of rechargeable batteries.
