8 Exhaust and air filter
After assembly of your engine the exhaust can be installed.
• Place the two socket screws and rings through the manifold of the exhaust, put the gasket
on the two bolts and mount the manifold to your engines eahaust port.
• Place the teflon connection tube on the manifold end, secure in place with the clamp.
• Place clamp around the exhaust, now connect exhaust and manifold using the teflon
connection tube.
• Place bar through the end of the exhaust, secure the bar to the front mounting point of the
sideskirt.
• Set height of the exhaust that the exhaust output pipe just sits through the hole of the side
skirt, secure height with set screw at the exhaust end.
•
Place clamp on exhaust around the teflon connection tube.
After assembly of your engine the air filter can be installed.
• Place the o-ring in the o-ring groove of the air filter manifold.
• Place and secure the manifold onto the carb of your engine using M5x45 socket screws and
lock rings.
Note:
The air filter should be oiled with oil for air filters PRIOR of usig the car and for optimal protection of
your engine!
