10 Recommended parts
For completing the car we recommend following parts:
Steering servo: Multiplex, Rhino Digi4
Throttle Brake servo: Multiplex, Titan SHV Digi5
Engine: Zenoah engine 23CC/26CC by Komatsu or CY engine by Cyang Yung
These parts are all a direct fit to the Cleon MMX off-road buggy.
11 Cleon set-up
The Cleon off-road buggy is a top competition racing machine. It therefor features multiple points for adjusting and
mounting the parts. These points have been choosen carefully allowing you to quickly change and set-up the car
during a race.
Setting up a car is personal. Below are given some general guidelines to get you started.
We advise you not to make more than 1 adjustment per time unless you are very experienced and skilled. By
adjusting just 1 part in your set-up, you will be able to determine much better if it did improve the handeling of
your car or not.
We advise to make adjustments always equal on both s
ides of the car !
11.1 Roll centre
The roll centre can be changed at the front and the rear of the car.
At the front:
Front pin at upper wishbone
Characteristics
Front upper wishbone higher position
(recomended) = lower roll centre
Less responsive car
More steering on power
Fast long corners
Front upper wishbone in lower position = higher
roll centre
More responsive car
Decrease of steering on power
Avoids traction rolling
For high grip tracks with quick direction changes
At the rear:
Rear pin at upright
Characteristics
Rear upper wishbone in the lower position
(recomended) = lower roll centre
Decreases traction on power
Less camber gain
More traction when braking
Rear upper wishbone in the higher position =
higher roll centre
More responsive car
Avoids traction rolling
Use under low traction conditions
Increases traction on power
Decreases traction when braking
