15-6
EXPLODED VIEWS AND SPARE PARTS LISTS
Revision Y05-01
Service Manual - DNG Series
15.8 Outdoor Unit: GC 18 RC 1PH
SP No. Part No. Description Qty
1 4517144 COVER PP+UV 1
2 452795700 PAINTED LEFT CABINET ASSY 1
3 452989200 Base welding plate assy. 1
4 4516786 PAINTED RIGHT CABINET ASSY 1
5 4516985 Partition Plate 1
6 455000506 Compressor Capacitor With Screw 45uF (CBB65) 1
7 455000104 Double patch Capacitor for fan motor 4uF (CBB61S) 1
8 204107 Cable clip Nylon 2
9 4524907 contactor (CJX9B-25S/01) 1
10 4521744 3 Poles Terminal Block (4mm2) 1
11 4522469 4 LEVEL TERMINAL BLOCK 1
12 4521733 3 Poles Terminal Block ( 6mm2) 1
13 4521340 Controller Box 1
14 4525427 Clip for capacitance(d=50) 1
15 453089900 Compressor Assy.PA200X2CS-4KU1 1
16 4519000 Spring of compressor heater 1
17 4517345 COMPRESSOR WIRE ASSY. 2.5mm2 1
18 4526922 Heater for compressor 1
19 4516766 PAINTED VALVE PLATE ASSY 1
20 4526530 LOW PRESS VALVE (R410A) 1
21 4526531 High press valve(R410A) 1
22 4526931 filter welding assy. 2 1
23 4526839 filter welding assy. 1
24 4523145 R.lifter 1
25 4526840 Single-way welding assy. 1
26 4523338 Accumulator assy. 1
27 452976500 Suction pipe 2 1
28 452976600 Low pressure pipe 1
29 452976400 Condenser pipe assy. 1
30 4526291 Muffler 1
31 4525938 PAINTED RIGHT-BACK CABINET ASSY 1
32 4526522 FOUR-WAY VALVE ( ) R410A 1
33 4526589 4-Way Valve Coil FOR R410A 1
34 452976100 Discharge pipe 2 1
35 452987800 4-way welding assy. for GC18RC R410A PA200 1
36 4517028 PAINTED LEFT-BACK GRILL 1
37 4516758 SMALL HANDLE 1
38 452976000 Discharge pipe 1 1
39 452796500 Condenser-Distributing Soldering Assy.GC-18RC R410A 1
40 452988800 Insulation for compressor PA215/240 1
41 452976200 Suction pipe 1 1
42 4526509 MOTOR BRAKECT (new) 1
43 4526862 motor YYK85E-6B for GC18RC 1
44 4526585 connect for motor backet 1
45 4526510 FAN D=460mm (3 blade) 1
46 4523141 M10 Hexagon locked nut M10 1
47 4516788 PAINTED TOP COVER ASSY 1
To Next Page
