Electra DNG 18 - Outdoor Unit

UNIT DIMENSIONS
DISPOSAL OF OUTDOOR UNIT DRAIN WATER
In case of using a drain elbow, the unit should be placed on
a stand at least 3 cm high.
Install the hose with a downward to allow smooth flow of
draining water.
Use 16mm I.D. tube for drainage.
5m or more
0.5m
or more
Air
intake
side
Air
intake
side
1m
or
more
5cm
or
more
25cm
or
more
20cm
or
more
5m
or more
Air
intake
side
Row Installation Back to Back Front to Front
Front to Back
OUTDOOR UNIT
CAP.
5 Kw
6 Kw
9 Kw
10-13 Kw
14-16 Kw
A
610
680
860
970
1250
B
795
900
900
900
900
C
500
705
705
705
705
D
148
97
97
97
97
E
290
340
340
340
340
F
293
357
357
357
357
8
SEVERAL OUTDOORS INSTALATION
When installing several outdoors units please take into account
the air flow around the units and follow the minimum distance
suggestions as shown in the diagrams bellow.
CLEARENS AROUND THE UNIT
B
A
CD
E
F
5 CM
5 CM
100 CM
25 CM
APPENDIX A
