Electra DNG 18 - Electrical Data

8-1
ELECTRICAL DATA
Revision Y05-01Service Manual - DNG Series
8. ELECTRICAL DATA
8.1 Single Phase Units
MODEL DNG 18 DNG 24
Power Supply
To Indoor To Outdoor
1PH – 230V – 50 Hz 1PH – 230V – 50 Hz
Max Current, A 14
Circuit Breaker 20 20
Power Supply Wiring No. X
Cross Section mm
2
3 X 2.5 mm
2
3 X 2.5 mm
2
Interconnecting Cable RC
Model No. X Cross Section mm
2
5 X 2.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
Interconnecting Cable ST
Model No. X Cross Section mm
2
4 X 2.5 mm
2
+ 2 X 0.5 mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
MODEL DNG 30 DNG 37
Power Supply
To Outdoor To Outdoor
1PH – 230V – 50 Hz 1PH – 230V – 50 Hz
Max Current, A 17 23
Circuit Breaker 25 25
Power Supply Wiring No. X
Cross Section mm
2
3 X 4 mm
2
3 X 4 mm
2
Interconnecting Cable RC
Model No. X Cross Section mm
2
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
Interconnecting Cable ST
Model No. X Cross Section mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
8.2 Three Phase Units
MODEL DNG 18 DNG 24 DNG 30
Power Supply
To Outdoor To Outdoor To Outdoor
3PH – 400V – 50 Hz 3PH – 400V – 50 Hz 3PH – 400V – 50 Hz
Max Current, A 10
Circuit Breaker 3 X 10 3 X 10 3 X 16
Power Supply Wiring No. X
Cross Section mm
2
5 X 1.5 mm
2
5 X 1.5 mm
2
5 X 2.5 mm
2
Interconnecting Cable RC
Model No. X Cross Section mm
2
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
Interconnecting Cable ST
Model No. X Cross Section mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
MODEL DNG 37 DNG 44
Power Supply
To Outdoor To Outdoor
3PH – 400V – 50 Hz 3PH – 400V – 50 Hz
Max Current, A 12.5 17
Circuit Breaker 3 X 16 3 X 16
Power Supply Wiring No. X
Cross Section mm
2
5 X 2.5 mm
2
5 X 2.5 mm
2
Interconnecting Cable RC
Model No. X Cross Section mm
2
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
6 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
Interconnecting Cable ST
Model No. X Cross Section mm
2
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
5 X 1.5 mm
2
+ 2 X 0.5 mm
2
(OCT Sensor)
NOTE: Power wiring cord should comply with local lows and electrical regulations
requirements.
