Electra DNG 18 - Ou10

2-7
PRODUCT DATA SHEET
Revision Y05-01Service Manual - DNG Series
Model Indoor Unit DNG 37
Model Outdoor Unit OU10-36 R410A
Installation Method DUCTED
Characteristics Units Cooling Heating
Btu/hr 36350 38200
Capacity
(1)
kW 10.6 11.2
Power Input
(1)
kW 3.8 3.7
COP
(1)
W/W 2.81 3.05
Energy Efficiency Class C D
Power Supply V/Ph/Hz 230/50/1
Rated Current A 16.9 16.3
Starting Current A 92
Circuit Breaker Rating A 25
Fan Type & Quantity
CENTRIFUGAL X1
Fan Speed H/M/L RPM 775 650 540
Airflow
(2)
H/M/L M
3
/hr 1840 1520 1210
External Static Pressure Min-Max Pa 37-100
Sound Power Level
(3)
H/M/L dB (A) 67 63 60
Sound Pressure Level
(4)
H/M/L dB (A) 51 48 45
Moisture Removal L/hr 3.7
Condensate Drain Tube I.D. mm 22
Dimensions
W/H/D mm 835 300 755
Weight kg 33
Package Dimensions W/H/D mm 1010 342 917
Packaged Weight kg 35
Units per Pallet Units 6
INDOOR
Stacking Height Units 6
Refrigerant Control
Capillary
Compressor Type, Model Rotary
Fan Type & Quantity Axial & 1
Fan Speeds H/L RPM 1125
Airflow
H/L M
3
/hr 4150
Sound Power Level H/L dB (A) 70.9
Sound Pressure Level
(4)
H/L dB (A) 63
Dimensions W/H/D mm 900 970 340
Weight kg 87
Package Dimensions W/H/D mm 985 1020 435
Packaged Weight kg 91
Units per Pallet Units 6
Stacking Height Units 2
Refrigerant Type R 410A
Refrigerant Chargeless Distance kg/m 2.55/ 15
Additional Charge Per 1 Meter g/m 25
Liquid Line In 3/8
Suction Line In 3/4
Max. Tubing Length m 50
OUTDOOR
Connections
Between Units
Max. Height Difference m 25
Operation Control Type
LCD Remote Control
Heating Elements kW
Others Crankcase heater (50W)
